General Specifications | ||
Name | AMD Ryzen™ 5 7500F | |
Family | Ryzen | |
Series | Ryzen 7000 Series | |
Market Segment | Enthusiast Desktop | |
AMD PRO Technologies | No | |
Consumer Use | Yes | |
Regional Availability | Global | |
Former Codename | Raphael AM5 | |
Architecture | Zen 4 | |
# of CPU Cores | 6 | |
Multithreading (SMT) | Yes | |
# of Threads | 12 | |
Max. Boost Clock | Up to 5 GHz | |
Base Clock | 3.7 GHz | |
L1 Cache | 384 KB | |
L2 Cache | 6 MB | |
L3 Cache | 32 MB | |
Default TDP | 65W | |
Processor Technology for CPU Cores | TSMC 5nm FinFET | |
Processor Technology for I/O Die | TSMC 6nm FinFET | |
CPU Compute Die (CCD) Size | 71mm² | |
I/O Die (IOD) Size | 122mm² | |
Package Die Count | 2 | |
Unlocked for Overclocking | Yes | |
AMD EXPO™ Memory Overclocking Technology | Yes | |
Precision Boost Overdrive | Yes | |
Curve Optimizer Voltage Offsets | Yes | |
AMD Ryzen™ Master Support | Yes | |
CPU Socket | AM5 | |
Supporting Chipsets | A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 | |
CPU Boost Technology | Precision Boost 2 | |
Instruction Set | x86-64 | |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , | |
SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 | ||
| ||
| ||
Max. Operating Temperature (Tjmax) | 95°C | |
Launch Date | 7/22/2023 | |
OS Support | Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , | |
RHEL x86 64-Bit , Ubuntu x86 64-Bit | ||
Connectivity | ||
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 | |
Native USB 3.2 Gen 1 (5Gbps) Ports | 0 | |
Native USB 2.0 (480Mbps) Ports | 1 | |
Native SATA Ports | 0 | |
PCI Express® Version | PCIe® 5.0 | |
Native PCIe® Lanes (Total/Usable) | 28 , 24 | |
Additional Usable PCIe Lanes from Motherboard | X670E | |
12x Gen4 | ||
X670 | ||
12x Gen4 | ||
B650E | ||
8x Gen4 | ||
B650 | ||
8x Gen4 | ||
A620 | ||
4x Gen3 | ||
NVMe Support | Boot , RAID0 , RAID1 , RAID10 | |
System Memory Type | DDR5 | |
Memory Channels | 2 | |
Max. Memory | 128 GB | |
System Memory Subtype | UDIMM | |
Max Memory Speed | 2x1R | |
DDR5-5200 | ||
2x2R | ||
DDR5-5200 | ||
4x1R | ||
DDR5-3600 | ||
4x2R | ||
DDR5-3600 | ||
ECC Support | Yes (Requires mobo support) | |
Graphics Capabilities | ||
Graphics Model | Discrete Graphics Card Required |
