AMD Ryzen™ 9 7900X3D Gaming Processor
The Insanely Powerful Gaming and Streaming Desktop Processor, with AMD 3D V-Cache™ Technology for Even More Game Performance
With this enthusiast processor you can enjoy extreme performance for gaming, creating, streaming, or whatever workload you choose. Plus, enjoy the benefits of next-gen AMD 3D V-Cache™ technology for low latency and even more game performance.
General Specifications
Name: AMD Ryzen™ 9 7900X3D
Family: Ryzen
Series: Ryzen 7000 Series
Form Factor: Desktops , Boxed Processor
Market Segment: Enthusiast Desktop
AMD PRO Technologies: No
Consumer Use: Yes
Regional Availability: Global
Former Codename: Raphael AM5
Architecture: Zen 4
# of CPU Cores: 12
Multithreading (SMT): Yes
# of Threads: 24
Max. Boost Clock: Up to 5.6 GHz
Base Clock: 4.4 GHz
L1 Cache: 768 KB
L2 Cache: 12 MB
L3 Cache: 128 MB
Default TDP: 120W
Processor Technology for CPU Cores: TSMC 5nm FinFET
Processor Technology for I/O Die: TSMC 6nm FinFET
CPU Compute Die (CCD) Size: 71mm²
I/O Die (IOD) Size: 122mm²
Package Die Count: 3
AMD EXPO™ Memory Overclocking Technology: Yes
Precision Boost Overdrive: Yes
Curve Optimizer Voltage Offsets: Yes
AMD Ryzen™ Master Support: Yes
CPU Socket: AM5
Supporting Chipsets: A620 , X670E , X670 , B650E , B650
CPU Boost Technology: Precision Boost 2
Instruction Set: x86-64
Supported Extensions: AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB):Not Included
Recommended Cooler: Liquid cooler recommended for optimal performance
Max. Operating Temperature (Tjmax):89°C
*OS Support: Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
Native USB 3.2 Gen 2 (10Gbps) Ports: 4
Native USB 3.2 Gen 1 (5Gbps) Ports: 0
Native USB 2.0 (480Mbps) Ports: 1
Native SATA Ports: 0
PCI Express® Version: PCIe® 5.0
Native PCIe® Lanes (Total/Usable): 28 , 24
Additional Usable PCIe Lanes from Motherboard:
X670E 12x Gen4
X670 12x Gen4
B650E 8x Gen4
B650 8x Gen4
NVMe Support: Boot , RAID0 , RAID1 , RAID10
System Memory Type: DDR5
Memory Channels: 2
Max. Memory: 128 GB
System Memory Subtype: UDIMM
Max Memory Speed:
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600
ECC Support: Yes (Requires mobo support)
Key Features
Supported Technologies: AMD EXPO™ Technology , AMD Ryzen™ Technologies
